Optical tracking systems in the NFL have become increasingly sophisticated, aiming to enhance the accuracy of game measurements and reduce human error. designed to improve the accuracy of line-to-gain rulings and speeding up the game by providing more precise measurement. This system uses high-resolution cameras to track the position of the ball, potentially replacing the traditional “chain gang” method.
“Lights, Camera, Action!” The total number of cameras (for accuracy) used during an NFL game is roughly 120 to 180 cameras.
- Hawk-Eye Innovations: Around 14 cameras.
- Second Spectrum: Typically 10 to 12 cameras.
- ChyronHego TRACAB: About 9 cameras.
- Catapult Sports: Primarily uses wearable tech, so no fixed number of cameras – 12 to 20 cameras to track.
- STATSports: Focuses on wearable technology, not specific cameras – 12 to 20 cameras to track.
- Kinexon: Uses sensors for tracking, not cameras – 12 to 20 cameras to track.
- Sportlogiq:1 or 2 cameras.
- Zebra Technologies: Approximately 21 cameras.
- Intel True View: Around 40 5k cameras.
- Vicon: Estimated 20 cameras.
Here’s a detailed overview of the key optical tracking systems currently being used or tested in the NFL.
1. Hawk-Eye Innovations
Hawk-Eye, widely known for its use in tennis and cricket, has been adapted for NFL use. This system employs multiple high-speed cameras positioned around the stadium to track the ball and players in real-time. The cameras capture data points that are processed to create a 3D representation of the field, allowing for precise measurements of ball placement and player movements.
Key Features:
- High-Speed Cameras: Multiple cameras capture data at high frame rates.
- High Resolution: Hawk-Eye cameras can capture images at resolutions up to 4K (3840 x 2160 pixels) or higher, depending on the specific model and application.
- Frame Rate: These cameras can operate at high frame rates, typically ranging from 100 to 1,000 frames per second (fps), allowing them to capture fast-moving objects with great detail.
- 3D Modeling: Creates a three-dimensional model of the field and players.
- Real-Time Data: Provides instant feedback on ball and player positions.
For major events like the Super Bowl, it can have up to 59 cameras covering the action.
2. Second Spectrum
Second Spectrum is another advanced optical tracking system used in the NFL. It utilizes a combination of cameras and machine learning algorithms to track player movements and ball trajectories. This system is particularly noted for its ability to provide detailed analytics and insights into player performance and game strategy.
Key Features:
- Interactive Broadcast Solutions: Second Spectrum’s technology integrates advanced data with augmented video content, offering a more immersive viewing experience.
- Resolution: High-definition (HD) cameras, typically up to 4K (3840 x 2160 pixels), to capture detailed images and videos.
- Frame Rate: These cameras can capture data at high frame rates, often around 25 frames per second (fps) for tracking purposes.
- Data Capture: The system captures the location of every player, the referees, and the ball 25 times per second, providing precise and detailed tracking information.
- Machine Learning: Uses AI to improve tracking accuracy over time. It automatically indexes actions on the field, providing detailed insights and analytics.
- Detailed Analytics: Offers in-depth analysis of strategic planning, player movements and game dynamics.
- Real-Time Augmentation: Their real-time augmentation engine integrates data into NFL broadcasts, providing innovative ways for fans to engage with the game.
Second Spectrum’s tracking system typically uses a network of 10 to 12 high-speed cameras strategically placed around the stadium to capture comprehensive data on player and ball movements
3. ChyronHego TRACAB
TRACAB, developed by ChyronHego, is a widely used optical tracking system in various sports, including the NFL. It employs a combination of fixed and mobile cameras to capture the entire field. The system uses advanced image processing techniques to track the ball and players, providing accurate positional data.
Key Features:
- Fixed and Mobile Cameras: Ensures comprehensive coverage of the field.
- Resolution: Super-HD, which typically means resolutions up to 4K (3840 x 2160 pixels) or higher.
- Frame Rate: High frame rates to capture fast movements with minimal delay, often up to 1000 frames per second (fps).
- Stereo Technology: Uses stereo camera units to ensure the entire playing surface is constantly filmed from multiple angles.
- Latency: The system delivers live tracking data with a maximum delay of just three frames, ensuring near real-time accuracy.
- Image Processing: Utilizes sophisticated algorithms for precise tracking.
- Positional Data: Delivers accurate information on player and ball positions.
ChyronHego’s TRACAB system typically uses 8 to 10 cameras strategically placed around the stadium to capture comprehensive tracking data during a game
4. Catapult Sports
Catapult Sports offers an optical tracking system that combines video analysis with wearable technology. While primarily known for its wearable devices, Catapult’s optical tracking system uses high-definition cameras to capture game footage, which is then analyzed to provide insights into player performance and team strategies.
Key Features:
- Video Analysis: High-definition cameras capture detailed game footage.
- Resolution: Catapult’s cameras typically offer high-definition (HD) resolution, up to 4K (3840 x 2160 pixels), ensuring detailed and clear images.
- Frame Rate: These cameras can capture data at high frame rates, often around 100 frames per second (fps) or higher, to accurately track fast movements.
- Data Capture: The system captures detailed data on player movements, including speed, distance, and acceleration, providing comprehensive performance metrics.
- Wearable Integration: Combines data from wearables with optical tracking.
- Performance Insights: Provides comprehensive analysis of player and team performance.
For a full game setup, Catapult might use around 12 to 20 cameras to ensure comprehensive coverage of the field and accurate tracking of all players
5. STATSports
STATSports is another company that integrates optical tracking with wearable technology. Their system uses multiple cameras to track players and the ball, while also collecting data from GPS-enabled wearables. This combination allows for a detailed analysis of player movements, workload, and overall performance.
Key Features:
- Game Cameras:
- Resolution: High-definition (HD) cameras, typically up to 4K (3840 x 2160 pixels), to capture detailed images and videos.
- Frame Rate: These cameras can capture data at high frame rates, often around 25 frames per second (fps) for tracking purposes.
- Data Capture: The system captures the location of every player, the referees, and the ball 25 times per second, providing precise and detailed tracking information.
- GPS Integration: Combines optical tracking with GPS data from wearables.
- Player Workload: Monitors player workload and performance metrics.
- Comprehensive Analysis: Offers detailed insights into player and team dynamics.
*High-Speed Cameras: While the primary focus is on wearable devices, STATSports can use multiple high-speed cameras positioned around the stadium to capture detailed video footage. The number of cameras can vary, but typically, a setup might include around 12 to 20 cameras to ensure comprehensive coverage
6. Kinexon
Kinexon’s optical tracking system is known for its high precision and real-time data capabilities. It uses a network of cameras to track the ball and players, providing accurate positional data that can be used for game analysis and strategy development.
Key Features:
- High Precision: Delivers highly accurate tracking data.
- Resolution: High-definition (HD) cameras, typically up to 4K (3840 x 2160 pixels), ensuring detailed and clear images.
- Frame Rate: These cameras can capture data at high frame rates, often around 100 frames per second (fps) or higher, to accurately track fast movements.
- Data Capture: The system captures detailed data on player movements, including speed, distance, and acceleration, providing comprehensive performance metrics.
- Real-Time Capabilities: Provides instant feedback during games.
- Strategic Insights: Helps teams develop and refine game strategies.
*High-Speed Cameras: While the primary focus is on wearable devices, Kinexon can use multiple high-speed cameras positioned around the stadium to capture detailed video footage. The number of cameras can vary, but typically, a setup might include around 12 to 20 cameras to ensure comprehensive coverage.
7. Sportlogiq
Sportlogiq uses computer vision and machine learning to track player movements and ball trajectories. This system is particularly noted for its ability to provide advanced analytics and visualizations, helping teams and broadcasters enhance their understanding of the game.
Key Features:
- Computer Vision: Uses advanced image recognition technology.
- Resolution: Sportlogiq’s system can work with high-definition (HD) cameras, typically up to 4K (3840 x 2160 pixels), ensuring detailed and clear images.
- Frame Rate: The cameras can capture data at high frame rates, often around 30 frames per second (fps), to accurately track player movements and actions.
- Data Capture: The system captures detailed data on player movements, including speed, distance, and acceleration, providing comprehensive performance metrics.
- Machine Learning: Continuously improves tracking accuracy.
- Advanced Analytics: Offers detailed visualizations and insights.
One Camera Setup
- Single Camera: Sportlogiq’s system can operate effectively with a single camera feed. This is made possible through their advanced computer vision and AI technology, which extracts detailed data from the video feed.
8. Zebra Technologies
Zebra Technologies provides an optical tracking system that integrates with RFID technology. This system uses cameras to track the ball and players, while RFID tags embedded in player uniforms provide additional data points. This combination allows for a comprehensive analysis of player movements and game dynamics.
Key Features:
- Cameras:
- Resolution: Typically ranging from 2 to 16 Megapixels.
- Frame Rate: High-speed image capture to ensure detailed tracking of fast movements.
- Features: Integrated lens focusing, illumination intensity control, and real-time digital I/Os.
- RFID Integration: Combines optical tracking with RFID data.
- Comprehensive Coverage: Tracks both ball and player movements.
- Detailed Analysis: Provides in-depth insights into game dynamics.
Zebra Technologies’ optical tracking system in the NFL typically uses around 20 to 22 cameras strategically placed around the stadium to ensure comprehensive coverage of the field
9. Intel True View
Intel’s True View technology uses a network of high-definition cameras to create 360-degree replays and visualizations. This system captures detailed data on player movements and ball trajectories, allowing for immersive replays and advanced game analysis.
Key Features:
- 360-Degree Replays: Creates immersive replays from multiple angles.
- High-Definition Cameras: Captures detailed game footage.
- Resolution: 5K
- Frame Rate: High-speed image capture to handle fast-paced action.
- Features: These cameras capture volumetric data, which includes height, width, and depth, using voxels (3D pixels) to create detailed 3D replays.
- Advanced Visualizations: Provides in-depth analysis and insights.
30 to 50 Cameras: Each stadium equipped with Intel True View typically uses between 30 and 50 high-end 5K cameras. These cameras are strategically placed around the stadium to cover every angle of the field
10. Vicon
Vicon’s optical tracking system is known for its high accuracy and real-time capabilities. It uses a network of cameras to track the ball and players, providing precise positional data that can be used for game analysis and strategy development.
Key Features:
- High Accuracy: Delivers precise tracking data.
- Resolution: Up to 26 Megapixels (VK26 model).
- Frame Rate: Native speeds up to 500 FPS, and up to 2000 FPS with windowing techniques.
- Features: High precision, IP65-rated for durability, and equipped with varifocal lenses for increased range and precision
- Real-Time Feedback: Provides instant data during games.
- Strategic Insights: Helps teams refine their strategies.
The exact number of cameras used can vary, but a typical setup for comprehensive coverage in a stadium might involve up to 20 Cameras.
Bottom Line
Optical tracking systems in the NFL are revolutionizing the way the game is analyzed and understood. By providing accurate and real-time data on player movements and ball trajectories, these systems help teams develop better strategies, enhance player performance, and improve the overall fan experience. As technology continues to advance, we can expect even more sophisticated tracking systems to be implemented in the future, further transforming the landscape of NFL football.
